Rigid Plastic Insulating Bushing
TOPELE Plastic Insulating Bushing is designed to protect wires in threaded RIGID or IMC conduits,to prevent wires from being damaged by sharp edges on conduits. It made of heat-tolerant thermoplastic and can be used in indoor or outdoor environments. These bushings meet UL requirements.
Rigid Plastic Insulating Bushing
Basic details：
Material: | Plastic |
Type: | Female |
Size: | 1/2''-4'' |
Usage: | Used on threaded RIGID/IMC conduits to prevent wires from being damaged by sharp edged on conduits. |
Brand Name: | TOPELE |
Specifications:
| Item No. | Trade Size | Dim A(Inch) | Dim B(Inch) |
| PC-50 | 1/2'' | 1.056 | 0.786 | |
| PC-75 | 3/4'' | 1.318 | 0.985 | |
| PC-100 | 1'' | 1.588 | 1.260 | |
| PC-125 | 1-1/4'' | 1.955 | 1.594 | |
| PC-150 | 1-1/2'' | 2.190 | 1.831 | |
| PC-200 | 2'' | 2.681 | 2.323 | |
| PC-250 | 2-1/2'' | 3.248 | 2.776 | |
| PC-300 | 3'' | 3.871 | 3.465 | |
| PC-350 | 3-1/2'' | 4.365 | 3.895 | |
| PC-400 | 4'' | 5.012 | 4.449 |
Payment Terms:
1.T/T , L/L at sight
Shipping Terms:
FOB, CFR (CNF, C&F), CIF,EXW
Competitive Advantage:
+Quick Delivery: 15days for one 20ft container.
+Competitive Price.
+Good Quality: meet UL standard.
+Best Service: fast delivery, strong package, good price, timely and effective communication.
+Powerful Solution: fast and effective solution to problem.
