Romex Connectors
TOPELE Nonmetallic Cable Clamp Connector is designed for use to bond nonmetallic cable to box or enclosure. Naturally corrosion resistant zinc die cast construction with two screw assembly to assure a secure connection.UL listed to confirm the quality.
Romex Connectors
Field Names:
Non-Metallic Twin Screw Clamp Connectors, NM Clamp Connectors,Clamp Type Romex BX Cable Connector,Romex Connector for Nonmetallic Cable
Basic details：
Material: | Zinc |
| Finish: | Galvanized |
Type: | Female |
| Threaded: | NPT |
Size: | 3/8''-2'' |
Usage: | For use to bond nonmetallic cable to box or enclosure |
Brand Name: | TOPELE |
| Standard: | UL No. E506413 |
Specifications:
 | Item No. | Trade Size | Dim A(Inch) | Dim B(Inch) |
| RCN-25 | 3/8'' | 0.825 | 0.421 | |
| RCN-50 | 1/2'' | 0.825 | 0.421 | |
| RCN-75 | 3/4'' | 1.000 | 0.482 | |
| RCN-100 | 1'' | 1.285 | 0.780 | |
| RCN-125 | 1-1/4'' | 1.312 | 0.710 | |
| RCN-150 | 1-1/2'' | 1.453 | 0.817 | |
| RCN-200 | 2'' | 1.590 | 0.823 |
Payment Terms:
1.T/T , L/L at sight
Shipping Terms:
FOB, CFR (CNF, C&F), CIF,EXW
Competitive Advantage:
1.Body and locknut are die-cast of high-strength zinc alloy.
2.Clamp is made of galvanized steel ,screws are electrogalvanizing.
